The M10-BWFDR EPDM Thick End Ring is a replacement end-position sealing component used in the cassette arrangement of an M10-BWFDR semi-welded plate heat exchanger. It is designed for the special end sealing position and differs from the standard ammonia-side ring gasket.
The quoted specification is approximately OD Ø129.5 mm, ID Ø112.5 mm and section size 8.5 × 5.5 mm. Senovis PHE supplies replacement thick end rings according to confirmed drawings, dimensions and actual heat exchanger configuration.
This gasket is suitable for maintenance and overhaul of semi-welded plate heat exchanger gasket systems.
Aftermarket replacement part suitable for Alfa Laval equipment. This product is not manufactured or authorized by Alfa Laval.
